Product Specifications
|
Parameter |
Specification / Range |
|
Primary Feature |
Vertical height adjustment for pipe supports |
|
Adjustment Mechanism |
Threaded stem or slotted upright |
|
Typical Use |
Maintaining slope and reducing sag in piping systems |
|
Materials |
Steel with anti-corrosion coating |
|
MOQ |
100 pieces |
Supporting Pipes on Sloped or Uneven Runs
Piping systems rarely run perfectly level. Drainage lines require slope; process lines may need to match equipment elevations. This bracket includes a vertical adjustment mechanism-either a threaded stem or a slotted upright-that lets the installer set the support height precisely. This maintains the intended pipe grade without the need to bend or strain the pipe into position.
Distributing Load Across the Pipe Span
The bracket is positioned to provide intermediate support, reducing the span length between primary supports. This is important for preventing pipe sagging, which can lead to liquid accumulation and joint stress. The adjustable mechanism allows the installer to balance the load across the support points, ensuring even distribution.
Easy Adjustment During Installation
The adjustment mechanism uses a locking nut that holds the set height securely once the pipe is in place. The bracket can be adjusted up or down without disassembling the support structure, which is useful during the fine-tuning phase of installation. This reduces the need for shims or cutting the pipe supports to custom lengths.
Standard Procurement
MOQ is 100 pieces with 20-day typical lead time. The product is compatible with a range of pipe sizes, with bracket dimensions matched to the pipe diameter. Surface coating provides protection against environmental corrosion.
