Product Specifications
|
Parameter |
Specification / Range |
|
Function |
Anchoring pipes at thermal expansion joints |
|
Material |
Structural steel, zinc coated |
|
Bolt Compatibility |
Standard expansion anchor sizes (M8, M10, M12) |
|
Production Method |
Stamped steel, consistent dimensions across batches |
|
MOQ |
100 pieces |
Anchoring Pipes at Expansion Points
HVAC piping expands and contracts with temperature changes. At expansion joints, the pipe must be anchored securely while allowing linear movement along its axis. This bracket provides that function. It anchors the pipe firmly to the structure at the expansion joint, ensuring that the expansion compensator operates within its design parameters. The bracket is designed to handle the tensile and compressive loads that occur during thermal cycles.
Precision Stamping for Consistent Fit
The bracket is manufactured using stamped steel dies, ensuring consistency across large production runs. The bolt holes are accurately positioned to match standard expansion anchor spacing. This precision reduces on-site adjustments and speeds up installation, particularly important on large piping systems with many expansion points.
Material Selection for Strength
The steel thickness is selected to withstand the forces imposed by the pipe during thermal cycling. The bracket's design includes a U-shaped section that adds rigidity without adding unnecessary mass. The surface is treated with a zinc-based coating for corrosion resistance, extending service life.
Standard Production Lead Time
Minimum order quantity is 100 pieces. Production lead time is approximately 20 working days. The bracket is supplied with the appropriate fastening hardware unless otherwise specified.
